Power & charging
Solar panel specification: 6V / 1.4W; 150×57.5×T3.2mm. Battery specification: 3.7V / 1500mAh.
WALL & FLOOD
Ultra-thin Wall Lamp
MS-BD006
The MS-BD006 offers a shallow solar wall-lamp body with a choice of strip-lens or small-lens configurations. The two versions share the same listed dimensions, solar panel and battery specification, while their LED counts differ. This makes the optical choice central to model selection.
APPLICATION & SELECTION
A closer look at MS-BD006.
Use the product image to compare the lens appearance before choosing a version. Check the lamp depth and mounting space on the wall, then identify the selected lens type in the enquiry to keep the order specification clear.
Read our lighting selection guideDimensions & construction
Product dimensions: 185×157×36mm.
Light & controls
Options for LED configuration: SMD2835 × 130 pcs | SMD2835 × 75 pcs.
PRODUCT INFORMATION
Technical specifications.
Power values are the catalogue ratings for each configuration. Solar panel ratings are listed separately in the table.
36mm thickness.
| Variant | Power | Product size | Solar panel | Battery | LEDs |
|---|---|---|---|---|---|
| Strip lens | 80W | 185×157×36mm | 6V / 1.4W 150×57.5×T3.2mm | 3.7V / 1500mAh | SMD2835 × 130 pcs |
| Small lens | 80W | 185×157×36mm | 6V / 1.4W 150×57.5×T3.2mm | 3.7V / 1500mAh | SMD2835 × 75 pcs |
